DustBoss DB-60 Fusion Self-powered Dust Suppression System

BossTek's DustBoss DB-60 Fusion dust suppression system features a Tier 4 Final generator that features a dual-containment fuel cell, heavy gauge lockable enclosure and oversized brushless alternator. The DB-60 Fusion drives pressurized water through a circular stainless steel manifold with 30 atomizing spray nozzles, then launches millions of tiny droplets with a powerful fan that produces 30,000 cfm of air flow.  Atomized mist droplets of 50 to 200 microns in size are thrown out in a 200-ft. cone at an adjustable 0- to 50-degree elevation angle, capturing airborne dust particles and dragging them to the ground.

• 25-hp electric motor
• Delivers up to 62,800 sq. ft. of coverage

• Heavy-duty 4-cycle indirect injection diesel engine
• Sound attenuation for noise reduction
• Multi-voltage switch with utility power outlet in all voltage modes
• Digital engine/generator controller with single button stop/start
• 80-gal. fuel capacity
• Uses about 23 gpm to avoid pooling and runoff
• Touch screen panel encased in NEMA 3R cabinet; controls oscillation, booster pump, fan and water
• In-line 75 mesh, 200 micron filter
• Can be specified with special filtration to accommodate non-potable water sources
• Variable Frequency Drive (VFD) to precisely adjust fan speed
• Optional dosing pump for precise metering of additives to enhance particle control
